Syntek Digital Angle Finder Level 360 Degree Range Spirit Level Upright Inclinometer with Magnets Protractor Ruler
Price
$49.99
Save
$50.00
Quantity
Free worldwide shipping
Free returns
Sustainably made
Secure payments
Product was out of stock.
Vendor by: aliexpress
Description
Brand Name: syntek
Model Number: SPCF40022
is_customized: Yes
|
HOT SALE |
|
Product introduction Syntek Digital Spirit Level 400mm Features & Function |
| 0.1° Precision | |
| With built-in 4 strong magnets | |
| Flip-up LCD,reading always in upright position | |
| Measuring range of 0~360° | |
| Hold function to freeze measurements | |
| Absolute measurement and relative measurement conversation | |
| Auto power off | |
| Measures precise inclines in degree or mm/m (up to 100mm/m) | |
|
| Resolution | 0.1° |
| Accuracy | 0.2° |
| Measuring range | 4 x 90° (0~360°) |
| Working current | < 100µA |
| Work temperature | 5~50°C |
| Work humidity | ≤85% RH |
| Magnet | 4 built-in on base plate |
| Power | 2 x 1.5V AAA battery(Not included) |
| Battery Life | Approx.100 hours |
| Dimension | 416 x 50 x 21 mm (L x W x H) |
| About Package |
| Package weight | 0.43kg |
| Package Contents |
1 x Digital level with digital inclinometer 1 x English Instruction Manual 1 x Standard Packaging Box |
Note: The parcel will be sent without battery ,The battery type is 2 x 1.5V AAA battery
Digital Spirit Level 400mm
This digital level measure all angles in either 360° range or four 90°quadrants. It can display both degree and slope . Not only this instrument can measure the horizontal and vertical surface, it also can measure the angles of all slopes rise & fall.
Product Details
The blue display background light shines for a few seconds. Hold the digital spirit level to the object to be measured and read the currently measured angle on the display.
If you tilt the digital spirit level in an angle > 90° the display automatically flips over by 180° for better readability.
Double bubble design:Vertical Spirit Bubble and Horizontal Spirit Bubble.
The battery type is 2 x 1.5V LR03 AAA battery (Not included)
With 4 magnets
Functions
1.Vertical Spirit Bubble
2.Horizontal Spirit Bubble
3.ON/INC/ABS/OFF
4.LCD display
5.HOLD/light key
|
Key operation instructions
|
| "ON/INC/ABS/OFF" key |
1.Shortly press the "ON/INC/ABS/OFF" key to switch on the digital spirit level. 2.Shortly press the "ON/INC/ABS/OFF" key toggle between display the absolute angle (display shows ABS) and display the relative angle/the deviation of the angle(display shows INC). When switching to the INC mode,the device resets the display to zero degrees. The following measurement readings refer to this zero point. 3.Press and hold the"ON/INC/ABS/OFF" key for 3 seconds to switch off the digital spirit level. If you do not operate the device for approx. 5 minutes, the device switches off automatically.
|
| "HOLD/LIGHT" key: |
1.Press the "HOLD/LIGHT" key to freeze the currently measured value on the display. The background light shines. Press the "HOLD/LIGHT" key one more time to return and show the currently measured values. 2.Press and hold the "HOLD/LIGHT" key for 3 seconds to switch on or off the display background light. |
Product Size(Unite:mm)
The carton packaging
More Real Picture
|
Calibration The digital spirit level has been calibrated in the factory for maximum accuracy. If necessary, the digital spirit level can be recalibrated.
|
| 1. Switch off the digital spirit level. Place it on a flat and level surface. | 2.Press and hold the "HOLD/LIGHT" key. Then additionally press the "ON/INC/ABS/OFF" key . The number "-1-"is flashing onthe display. |
| 3.Press the "ON/INC/ABS/OFF" key once more. The number "-2-"is flashing on the display. | 4.Horizontally flip over the digital spirit level by 180° |
| 5. | 6.Then press the "ON/INC/ABS/OFF" key one more time to finish the calibration process. |
